Special Structures

With main forte of Structural deigns, S3M is also engaged in the Designing of special structures such as Tall Chimneys, Silos and Silo foundations, heavy machine foundations, diaphragm wall foundations and such.

S3M is consulted by many Clients for the Value engineering of special structures and retrieval of a failed structure designed by another party. S3M imparts timely and authentic guidance to Clients seeking opinion on the Life of old structures. It conducts on-site surveys for the health assessment of such structures and backs up the observations with support of non-destructive testing as found desirable.

Value Engineering services for designs by other agencies are sought from S3M for ensuring the stability of structure and also for optimization of cost of structure.

With a research-oriented approach and involvement in minute detailing of designs, S3M has a vast exposure of working on foreign codes and various software desirable for the design of Special structures.

  • Project Location Salient features
  • 22 Storeyed commercial building in Steel AHMEDABAD This was supposed to be the first multistoreyed commercia buidling in Ahmedabad in Steel.
  • Design of 80 meter height Chimney for SLIPCO Construction Pvt. Ltd. Nepanagar,MP S3M Design Approved by Tata Consulting Engineers
  • Rehabilitation of 4000 MT wagon loading silo for Adani Enterprise Limited Chattishgadh After collapse of conival hopper and subsequent damage of two RC floor below, the 50m talls structure was rechecked for residual strength and rehabilitation scheme was proposed for reuse. Complete demolition was not possible due to time constraint.
  • 8000m3 UG Tank for DCW Limited Dhrangadhra-Gujarat Options wokred out for open tank as well as covered tank to arrive at optimum cost.
  • 75m height Single flue reinforced concrete Chimney for Magadh Sugar & Energy Limited Sidhwalia, Bihar Chimney being special structure, designed considering all dynamic loadings and as per latest Indian standard codes
